Druck - PTX661 Hammer Union Pressure Transmitter

PTX661 Pressure Transmitter (Drilling Mud Hammer Union Sensor) - OVERVIEW
by Druck

Features:
• ±0.1% full scale (FS) accuracy
• NACE compatible
• Intrinsically safe certified — ATEX, IECEx, NEPSI and FM Approved (United States and Canada)
• CE marked
• Fast response time (2 kHz)
• Repairable

PTX661 Pressure Transmitter (Drilling Mud Hammer Union Sensor) - DESCRIPTION
by Druck

The PTX 661 hammer union pressure transmitter is designed for use in extremely harsh environments, in both on-shore and off-shore oil drilling operations, where high shock and vibration are likely to be encountered. The transmitter is available in both the1502 and 2202 WECO® wing union configurations, both of which are NACE sour gas compatible.

The PTX 661 differs from other hammer union pressure transmitters in that it has a replaceable pressure transmitter insert (PTX 721-8518) which substantially reduces the cost of total transmitter replacement. With a 2 kHz response time, the device is suitable for measuring static and dynamic mud pressure.

The PTX 661 incorporates Druck’s proprietary high-accuracy silicon sensor with up to 2.5 times better accuracy than many competitive devices. The low-volume oil-fill technology allows response times of faster than 2 kHz. The field-proven 4 to 20 mA electronics, packaged in a rugged enclosure, provide power supply regulation, reverse polarity, over voltage and EMC protection. The fully encapsulated design provides exceptional reliability in high shock and vibration environments.

PTX661 Pressure Transmitter (Drilling Mud Hammer Union Sensor) - DOCUMENTATION
by Druck

DATASHEET:
PTX661 Pressure Transmitter (Drilling Mud Hammer Union Sensor)

INSTRUCTIONS:
PTX661 Pressure Transmitter (Drilling Mud Hammer Union Sensor)

PTX661 Pressure Transmitter (Drilling Mud Hammer Union Sensor) - ACCESSORIES
by Druck

Please consider these optional accessories:

	Druck - Insertion/Extraction Tool (P/N: F2186-1)	$1,187.00
	Druck - Replaceable pressure transmitter insert (P/N: PTX 721-8518)	$1,744.00
